TIG 200
Features:
IGBT Inverter welder ,
TIG &MMA welder
Smoothly arc striking,
User friendly panel ,
Easy to operate ,
Adjustable Gas post flow time ,
Adjustable Arc force current ,
| Parameters | TIG 200 |
| Input Voltage (V) | AC220V |
| Frequency (Hz) | 50/60 |
| Phase | 1 |
| Rated Input Current (A) | TIG :29 , MMA :27 |
| Rated Input Power (KVA) | TIG :6.4,MMA :5.9 |
| No-load Voltage (V) | 53 |
| Welding Current (A) | TIG:15~200,MMA :15~160 |
| Welding voltage(V) | TIG:10.6~18,MMA :20.6~26.4 |
| Rated Duty Cycle(%) 40℃ | 20% |
| Insulation Grade | F |
| Protection Class | IP21S |
| Cooling | Air |
| Dimension(mm) | 400*160*332 |
| Weight(Kg) | 7.7 |
