MIG 300DV
Features:
IGBT Inverter technology
MIG ,MMA function .
Display output voltage and current ,
constanct stable arc
Easy to operate ;
With wire select .
With spatter control ,
With high speed wire feeder .
With 2T/4T function ,
| Parameters | MIG 300DV | ||
| Input Voltage (V) | AC220V | AC380V | AC440V |
| Frequency (Hz) | 50/60 | 50/60 | 50/60 |
| Phase | 1 | 3 | 3 |
| Rated Input Current (A)(MIG) | 48 | 19 | 18 |
| Rated Input Current (A)(MMA) | 40 | 16 | 15 |
| Rated Input Power (KVA)(MIG ) | 10.6 | 12.6 | 11.9 |
| Rated Input Power (KVA)(MMA ) | 8.8 | 10.5 | 9.9 |
| Wire feeding speed（M/MIN) | 2.0-24 | 2.0-24 | 2.0-24 |
| Welding Current (A)(MIG ) | 50-250 | 50-300 | 50-300 |
| Welding Current (A)(MMA ) | 50-200 | 50-250 | 50-250 |
| Welding voltage(V) | 16.5-26.5 | 16.5-29 | 16.5-29 |
| No-load Voltage (V) | 62 | 55 | 65 |
| Rated Duty Cycle(%) 40℃(MIG ) | 50 | 35 | 35 |
| Rated Duty Cycle(%) 40℃(MMA ) | 60 | 60 | 60 |
| Wire diameter (mm) | 0.8/1.0 | 0.8/1.0/1.2 | |
| Protection Class | IP21S | ||
| Insulation Grade | F | ||
| Dimension(mm) | 604*250*571 | ||
| Weight(Kg) | 25 | ||
