IGBT Module Inverter Series MAX AC\DC TIG 400D.P


1. Adopt PWM control technology, provided with constant output current.

2. IGBT inverter with high efficiency; good functional performance of adjustment, multi-functions machine, convenient for use.

3. Excellent high frequency arc ignition, up to nearly 100% success rate, improve work efficiency.

4. Arc keeps stable when current is small, superb for welding thin plate.

5. With pulse welding function; wide adjust range of pulse frequency.

6. Adjustable Clean width and Clean scope to meet high technical requirements.

7. Wide usage range,could weld almost all non-ferrous metal, specical design for welding Aluminum.

8. Multifunction welding: AC TIG,AC pulse TIG,DC TIG,DC pulse TIG, MMA and Auto welding(easy operate at Auto welding ,only adjust welding current , preset other parameter at internal).

9.  Strong ability of anti-fluctuation of power supply, the ratio reaches 15% ( industrial requirement 10%).

10. Optional with water cooling box or tool box.

Technical   ParametersMAX AC\DC TIG   400D.P
Rated Input Voltage (V)3PH380V
Power Frequency(Hz)50/60
Rated Input CurrentA27
Rated Input Power(KVA)17.8
No-load Voltage(V)61
Pulse Frequency(Hz)0.2-500(DC),0.2-20(AC)
AC Frequency(Hz)20-150
Rated Duty Cycle(%)40℃)60
Protection ClassIP21S
Net Weight(Kg)59
