CUT 80C
Model Parameters | CUT 80C |
Rated Input Voltage (V) | AC380V |
Power Frequency(Hz) | 50/60Hz |
Phase | 3 |
Rated Input Current(A) | 23 |
Rated Input Power(KVA) | 15.1 |
No-load Voltage(V) | 310V |
Rated load voltage(V) | 112V |
Cutting Current(A) | CUT :25-80A, MMA:40-200A |
Rated Duty Cycle %(40℃) | CUT:40%(40℃) , MMA:100%(40℃) |
Efficiency | ≥85% |
Inverter air plasma cutter
Built-in air compressor
CUT 80C
Features :
IGBT inverter technology ,
User friendly panel ,
Built-in air compressor , easy to operate ,
Optional inner or outer compressor,
Adjustable post-flow gas time ,
Max cutting thickness :35mm ,
With 2T/4T function
CUT/MMA function
