TIG 255
Multi voltage TIG/ARC:1PH&3PH 160V-460V
. IGBT full bridge inverter ;
.Instant arc ingition speed ;
. User friendly panel , Easy to operate ;
.Both functiion : TIG , MMA ;
.with 2T/4T funciton, with display meter ;
.adjustable post flow at time at TIG and ARC start at MMA ;
| Parameters | TIG 255 | |
| Rated Input Voltage(V) | AC220V | AC380V |
| Power Frequency(Hz) | 50/60Hz | |
| Phase | 1 | 3 |
| Rated Input Current(A) | 20(TIG) 31(MMA) | 13(TIG) 17(MMA) |
| Rated Input Power(KVA) | 4.4(TIG) 6.8(MMA) | 8.6(TIG) 11.1(MMA) |
| Rated No-load Voltage(V) | 68 | 67 |
| Welding Current(A) | 15-160 | 15-250 |
| Rated Duty Cyvle%(40℃) | 100% | 60% |
| Protection Class | IP21S | |
| Dimensions(mm) | 530X250X430 | |
| Weight(Kg) | 16.7 | |
